Tracteur agricole neuf FOTON LOVOL TG1254

TG1254 LOVOL tractor

from: 50HP--200HP

Technical parametersBranch out allContract allTechnical parameters

Drive type 4*4

Overall dimension(L * W * H) 5250×2450×3030

Wheelbase (mm) 2688

Track(front/rear) 1720-2100/1680-2380single, (2380double)

Track(front/rear)regulating method Step/stepless

Minimum ground clearance 400

Min.operating weight(kg) 6700

Counterweight (max) (front/rear) 420/480

Gears(forward/reverse/creeper) 16+16

Theoretical speed of each gear(forward/reverse) 3.42-34.03/2.33-23.22

Engine

Brand Lovol Power

Engine type In-line, four-stroke

Intake mode Supercharged

Cylinder number 6

Bore 100

Stroke 127

Displacement(L) 6

Engine rated power kW@rpm 92

Rated speed 2200

Air cleaner type Dry type

Type of cooling system Forced water-cooled

Max. Torque@ revolving speed (rpm) 475/1600±100

Specific fuel consumption at rated conditions (g/kW.h) ≤248

Fuel tank capacity 350

Steering brake system

Type of steering system Hydraulic steering

Type of steering gear Cycloid orbitrol steering gear

Type of braking system Disc type (monochip), hydraulic control

Transmission system

Clutch type Dry type, double-action clutch

Gearbox type Two-axis mechanical gearbox

Gearbox shift mode Shift sleeve/synchro

Type of central transmission Spiral bevel gear type

Final transmission mode(front/rear) Single-stage planetary bevel gear/built-in single-stage planetary gear
